  • VTSYIQI Surface Roughness Tester Profile Gauge Surftest Profilometer Metal Surface Roughness Gauge with Data Storage Multiple Parameters Ra 0.005 to 16.000 Rz 0.02 to 160.00

VTSYIQI

VTSYIQI Surface Roughness Tester Profile Gauge Surftest Profilometer Metal Surface Roughness Gauge with Data Storage Multiple Parameters Ra 0.005 to 16.000 Rz 0.02 to 160.00

$90900
In stock
$90900

Customer Service

Post your customer service details here.

Return Policy

Post your policy conditions details here.

  • Product Description

  • Testing parameters: Ra, Rz, Rq, Rt, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rku, Rsm, Rmr, Rx
  • Measuring range (um): Ra: 0.005-16.000; Rz: 0.02-160.00
  • Sample length (mm): 0.25, 0.80, 2.50
  • Evaluation length(mm): (1-5)L
  • Maximum drive stroke: 17.5mm/0.7inch

Main feature:

* Electromechanical integration design, small volume, light weight, easy to use;

* Using DSP chip to control and data processing, high speed, low power consumption;

* 128 x 64 OLED dot matrix display, digital / graphic display; highlight no perspective;

* Intuitive and rich display information, can display all the parameters and graphics;

* Compatible with ISO, DIN, ANSI, JIS national standards;

* Residual quantity icon, prompting the user to charge;

* Continuous working time: more than 20 hours.

* Real-time clock settings and display, convenient data recording and storage.

* With automatic dormancy, automatic shutdown and power saving function

* Reliable control motor to go dead circuit and software design

* Measurement information display, menu prompt information, false information and switch machine and other tips that information;

* Plastic shell, inspired by “TRANSFORMERS” stylish design, portable, high reliability.

Technical Specifications

* Testing parameters: Ra, Rz, Rq, Rt, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rku, Rsm, Rmr, Rx;

* Measuring range (um): Ra: 0.005-16.000; Rz: 0.02-160.00

* Sample length (mm): 0.25, 0.80, 2.50

* Evaluation length(mm): (1-5)L

* Maximum drive stroke: 17.5mm/0.7inch

* Indication accuracy: 0.001

* Indication error: ±(7-10)%

* Variability: <6%

* Data Storage: 100 groups

* Power: Rechargeable li-battery

* Working temperature: -20℃~40℃; Relative humidity: <90%

* Size: 158mmx63.5mmx46mm

* Weight of Host: 0.3kg

* Standard Accessories: Host ,Standard Sensor,Calibration block and bracket, Charger,Adjustable support,Operating manual,Certificate of approval,Instrument case
