VTSYIQI Chlorine Gas Monitor Portable Cl2 Gas Detector with Measruing Range 0 to 20ppm Resolution 0.1ppm L-alarm 5ppm H-alarm 10ppm Output Current 4-20mA

VTSYIQI Chlorine Gas Monitor Portable Cl2 Gas Detector with Measruing Range 0 to 20ppm Resolution 0.1ppm L-alarm 5ppm H-alarm 10ppm Output Current 4-20mA

About this item：

♡Range:0-20ppm

♡Resolution:0.1ppm

♡L-alarm:5ppm ; H-alarm:10ppm

♡Output current:4-20mA

♡It is used to detect the concentration of flammable gas or other toxic and harmful gases in the air. When the concentration reaches or exceeds the preset alarm value, the controller will sound and light an alarm to promptly remind to take safety measures to prevent explosion and poisoning accidents, so as to protect life and property.

Overview:

It is used to detect the concentration of flammable gas or other toxic and harmful gases in the air. When the concentration reaches or exceeds the preset alarm value, the controller will sound and light an alarm to promptly remind to take safety measures to prevent explosion and poisoning accidents, so as to protect life and property.

This product has the advantages of stable signal, high precision, rapid response, long life, short polarization time, etc. It adopts industrial-grade sensor, the instrument shell is designed with explosion-proof structure, 4-20mA standard signal or directly into the DOS system, and can be widely used in metallurgy, petroleum, chemical, municipal and other industries, and is in the leading level of similar products in China. The housing adopts die-casting aluminum shell with explosion-proof structure design, the groove design of the upper cover can lock the housing, the front side of the sensor is designed with downward structure to ensure good contact between the sensor and the gas, and the inlet port adopts explosion-proof waterproof connector.

Features:

Measuring object: Chlorine Cl2

Range:0-20ppm

Resolution:0.1ppm

L-alarm:5ppm; H-alarm:10ppm

Product type:Fixed gas detector/transmitter

Response time:<30S

Power supply:DC24V±10%

Working temperature:-10℃～55℃

Output current:4-20mA

Working humidity:0-95%RH (Non-condensing)

Contact output:Free contact output, max power 1kW

Single input:4~20mA and RS485

Installation method:Wall-mounted

Shell material:Aluminum
