VTSYIQI Digital Color Meter Colorimeter with Switchable Caliber 4mm/8mm IPS Full Color Touch Screen Auto Calibration Data Storage Function

Digital Color Meter Colorimeter with Switchable Caliber 4mm/8mm IPS Full Color Touch Screen Auto Calibration Data Storage Function

Digital Colorimeter Spectrophotometer with Aperture 8mm Auto Calibration IPS Full Color Touch Screen USB Data Storage Function

Spectral colorimeter series are economical models to measure the color difference. Instrument is with auto calibration to make it simple in operation. It contains 30 kinds of parameters and 26 kinds of illuminants.

Introduction:

• Spectral colorimeter series are economical models to measure the color difference.
• Instrument is with auto calibration to make it simple in operation. It contains 30 kinds of parameters and 26 kinds of illuminants.

Features:

1. Different apertures: Big Aperture 8MM
2. Auto calibration
3. SCI/SCE:It supports both SCI and SCE test which is more consistent with result of visual method.
4. Many different kinds of test parameters:Opacity, whiteness index, yellowness index and other 30 kinds of test parameters
5. Provide 26 Kinds of Illuminants for Choice
6. Good repeatability for stable measurement (Delta E*ab 0.08)

Technical Specifications:

• Color:Green
• Geometry:D/8 (diffused illumination,8 degree viewing),SCI (specular component included),SCE (specular component excluded)
• Repeatability:Chromaticity Value:Standard deviation ΔE*ab≤ 0.04;Average : dE*ab≤ 0.05;Max.: dE*ab≤ 0.08;(when a white tile is measured 30 times at 5 seconds interval)
• Inter-instrument Agreement:ΔE*ab≤0.4
• Display Accuracy:0.01
• Test Aperture:Φ4mm+8mm
• Color Space and Indices:Reflectance, CIE-Lab, CIE-LCh, Hunter Lab, CIE-Luv, XYZ, Yxy, RGB, Color Difference (ΔE*ab, ΔE*cmc, ΔE*94, ΔE*00), Whiteness Index (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, Taube Berger Stensby), Yellowness Index(ASTM D1925, ASTM E313-00, ASTM E313-73), Blackness Index(My,dM), Staining Fastness, Color Fastness, Tint(ASTM E313-00), Color Density CMYK(A,T,E,M), Metamerism Index Milm, Munsell, Opacity, Color Strength
• Illuminants:A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84
• Support Color Matching Software:NO
• Light Source:LED

• Camera:NO
• Calibration:Auto
• Software:Windows
• Observer:2°，10°
• Sphere Size:40mm
• Standard:Conform to CIE No.15，GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7
• Spectroscopic Method:Integrated optics
• Sensor:CMOS Sensor
• Wavelength:10nm
• Wavelength:400-700nm
• Reflectance:0-200%
• Reflectance:0.01%
• Reflectance:0.01%
• Measurement:About 1 second
• Screen:IPS full color screen ,2.4 inches
• Battery:Rechargeable, 8,000 times continuous tests, 3.7V/3000mAh
• Light Source:10 years, 1 million tests
• Language:Chinese and English
• Storage:APP Mass Storage
