VTSYIQI Portable Haze meter Haze Measurement Handheld Haze Meter with Measuring Aperture 21mm Range 0-100% Resolution 0.1% for Thin Film Tempered Glass Haze Test

VTSYIQI Portable Haze meter Haze Measurement Handheld Haze Meter with Measuring Aperture 21mm Range 0-100% Resolution 0.1% for Thin Film Tempered Glass Haze Test

Regular price $1,140.00 USD
Regular price Sale price $1,140.00 USD
Sale Sold out
Shipping calculated at checkout.

VTSYIQI Portable Haze meter Haze Measurement Handheld Haze Meter with Measuring Aperture 21mm Range 0-100% Resolution 0.1% for Thin Film Tempered Glass Haze Test

Introduction:

The Haze Meter is compact in size, weighing only 1.13kg, making it easy to carry and measure haze and transmittance anytime and anywhere; 2.8-inch touch screen, connected to mini programs, massive storage; External power supply is required.

Feature:

Measure aperture:21mm

resolving power:0.1%

Repeatability:0.1

Light source: CIE-A, CIE-C, CIE-D65

Following standard: ASTM D1003/D1044, ISO 13468/ISO14782,JIS K 7105,JIS K 7361,JIS K 7136,GB/T 2410-08

Measurement parameters: haze and transmittance under both ASTM and ISO standards

Spectral response: CIE spectral function Y/V (λ)

Optical path structure: 0/d

Measurement aperture: 21mm

Range: 0-100%

Resolution: 0.1%

Repeatability: 0.1

Sample size: Thickness ≤ 40mm

Display: 2.8-inch touch screen

Storage data: massive storage

Interface: USB interface

Power supply: DC 5V/2A

Working temperature: 5-40 ℃, relative humidity of 80% or lower (at 35 ℃), no

condensation of water vapor

Storage temperature: -20 ℃~45 ℃, relative humidity of 80% or lower (at 35 ℃), no condensation of water vapor

Volume length X width X height: 133mmX99mmX224mm

Weight: 1.13kg

Optional: Customized Caliber Plate
