About this item

• Three-phase power analyzer Data* Real-time waveform display (4 cannleotvoltage/current)* True RMS values of voltages and currents.* Peak current and voltage* The maximum/minimum value of current and voltage over a period of time* Pharos diagram display* measurement of each phase, up to the 50th * Calculation of Total Distortion (THD)* Active/reactive/apparent power value and total value of each phase* Transformer K factor calculation
• 3-phase power analyzer is a comprehensive test instrument carefully developed by our company and specially designed for field test of three phases, multi-functional and intelligent, concise man-machine operation. It is easy to use, large LCD screen display, high resolution, interface in both Chinese and English, shock-proof shell structure and so on. Can simultaneously measure the 4-channel current (ABC three phase and neutral wire current), 4-channel voltage (ABC three-phase voltage and neutral line voltage to ground), the peak value of current voltage, maximum/minimum value over a period
• 3 phase power quality analyzer is a comprehensive test instrument specially designed by our company for three-phase, inr-functional, intelligent and simple man-machine operation Easy to use, large LCD color display, high resolution, bilingual interface in Chinese and Enalish. box structureandotherfaaturessimultaneousmeasurementof4 currents(ABC three-ohase and minimum vaoues voltages (ABC three -phase vollale and neutral to ground vollael current and vollage peaks, maximumreactive power, apparent power, power factor, displacement power factor, active energy, reactive energy, apparent energy,rarimonic ratio, total distortion Degree
• Energy quality analyzer In the current power applications, more and more large power equipment, power grid fault have become more and more complex, with development of the industry, it put forward high request more and more to quality that electric energy. We provide this power quality analyzer for that, which you can troubleshoot of complex power system more quickly and accurate, and monitoring and maintenance of power quality parameters more comprehensive and systemic.
• Power quality analyzer adopt DSP + ARM double processor architecture, DSP is use for data collection and the processing of algorithm, the ARM is use for the communication protocol and the man-machine interface processing; Analog signal acquisition is by 2 pieces ADC Chip of ADI company. Resolution for ADC Chip is 16 bit and it is 4 channel synchronous sampling. Power Quality Analyzer also named: Intelligent Three Phase Power Quality Analyzer, Multifunctional Power Quality Analyzer, which simultaneous with the functions of Analyzer, phase volt-ampere meter, electric parameter tester. It apply to electricity industry

Product Description
