VTSYIQI Rope Tension Meter Tester Gauge Digital Side Pressure Tension Gauge Pressuremeter with Wire Rope Diameter Φ24 to Φ36mm Maximum Load Value 100KN Load Division Value 0.1KN/ 0.01Mg/ 0.01Klb Three Units N kg Ib Conversion

VTSYIQI Rope Tension Meter Tester Gauge Digital Side Pressure Tension Gauge Pressuremeter with Wire Rope Diameter Φ24 to Φ36mm Maximum Load Value 100KN Load Division Value 0.1KN/ 0.01Mg/ 0.01Klb Three Units N kg Ib Conversion

About this item

❤❤(1)【Three Display Modes】Five test modes and three display modes are available to maximize the test efficiency. N (Newton), kg (kg), Ib (lb) three measurement units are available for selection and mutual conversion.

❤❤(2)【High Accuracy】 Gravity acceleration setting function - the user can input the exact value of the gravity acceleration of the place of use. Make test and unit conversion accurate. 6-bit large screen display.

❤❤(3)【Function】HD digital pressuremeter tension tester is a kind of special equipment to measure wind towers, signal transmission and power transmission systems rope tension.

❤❤(4)【Comparasion Value Setting】It can set the upper and lower limits and comparison values for statistical analysis. The buzzer alarm is exceeded for the comparison value. Environmental protection, automatic shutdown for 10 minutes without operation.

❤❤(5)【Charging Power Supply】 The charging voltage is available from 100V to 240V, which can be adapted to most areas in China and abroad. There are also short circuit, leakage, and overload protection.

Feature:
1, high precision and high resolution
2, five kinds of test patterns, three kinds of display modes are available for choice - Maximize the test efficiency;
3, N (Newton), kg (kilograms), lb (pounds) three kinds of measurement units for selection, mutual conversion;
4. Gravity acceleration setting function - The user can input the exact value of the gravity acceleration of the use place.Make test and unit conversion more accurate;
5, peak hold function.Keep the peak display until manually cleared;
6, automatic peak function, to maintain the peak display automatically after 2 seconds;
7, can set the upper and lower limits and comparative values do statistical analysis.Beep alarm exceeding the comparison value;
8, data storage function, can store 128 test values;
9, data output function, the data can be entered into the computer through the data line to do a variety of analysis;
10, green, 10 minutes no operation automatically shut down;
Technical Specifications
Wire rope pulling force: 10t
Maximum load value: 100KN
Wire rope diameter (mm): Φ24~Φ36; A(mm): 200; B(mm): 40; C(mm): 80
Load division value: 0.1KN/ 0.01Mg/ 0.01Klb
Error of indication: 土0.5%
Accuracy: According to the ropes characteristics of different forms, precision is the 2%-6% of the full range.
Unit: N(KN) , Kg(Mg or T) , Lb(Klb)
Power: Rechargeable batteries Battery voltage(100V-240V)
Sensor structure: high-accuracy External sensor
Work environment: No seismic focus and corrosive medium around
Net weight: About 400g weight of sensor
Size: 230 X 66 X 36mm
