VTSYIQI PH3 Gas Detector Wall-mounted Phosphine Gas Detector PH3 Gas Monitor with Range from 0 to 20ppm Resolution 0.1ppm for Detecting Gas of Metallurgical Industry and Refinery

VTSYIQI PH3 Gas Detector Wall-mounted Phosphine Gas Detector  PH3 Gas Monitor with Range from 0 to 20ppm Resolution 0.1ppm for Detecting Gas of Metallurgical Industry and Refinery

Introduction:

Fixed gas detector adopts advanced catalytic gas sensor or electrochemical sensor, which can translate the gas concentration in the air to the digital signal output.
The detector working with gas controller can be used to detect gas in refinery, chemical plant, LPG station, boiler room, painting plant and other places with gas exists.

Specification:

Product type:fixed gas detector/transmitter

Explosion proof grade:Exd ⅡC T6 Gb

Response time:≦30S

Power supply:DC24V±10%

Working temperature:-20℃～50℃

Output current:4-20mA

Working humidity:0-95%RH

Contact output:Free contact output, max power 1kW

Single input:4~20mA and RS485

Installation method:Wall-mounted

Shell material:Aluminum

Dimensions:190x150x95mm（L×W×H）

Model:PH3

Range:0-20ppm

Resolution:0.1ppm

L-alarm:5ppm

H-alarm:10ppm
